| Low Voltage | High Voltage | |
|---|---|---|
| Cooling | Water | |
| Capacity (pump model) | 1 On-Board (10, 400, 500) or 3 On-Board (100, 7, 8, 8F) | |
| Operating voltage | 180 - 253 VAC | 342 - 457 VAC / 50 Hz 342 - 506 VAC / 60 Hz |
| Line frequency | 50/60 Hz | |
| Phase | 3 | |
| Nominal input power | 5.5 kW | 5 kW / 50 Hz 5.5 kW / 60 Hz |
| Nominal power factor | 0.85 | |
| Rated full load / locked rotor current | 16.2 / 80 | 8 / 40 |
| Minimum electrical service | 30 Amps | 15 Amps |
| Maximum inlet temperature | 90°F (32°C) | |
| Minimum inlet temperature | 50°F (10°C) | |
| Flow rate | 2.75 ± 1.25 gpm (10.4 ± 4.7 lpm) | |
| Maximum inlet pressure | 100 psi (6.9 bars) | |
| Alkalinity | 6.0 - 8.0 pH | |
| Calcium carbonate | < 75 ppm | |
| Input power cable (Customer supplied) | 600 VAC 10 / 12 Gauge (LV / HV), 3 conductor wire with ground Must conform to local electrical codes | |
| Ambient operating temperature range | 50 - 100ºF (10 - 38ºC) | |
| Interface | Cryopump power receptacles: mates with the BROOKS-CRYOGENICS supplied cryopump power cable for single pump use. Mates with remote junction box power cable for multiple cryopump use. | |
| Gas supply connector | 1/2 in. Aeroquip self-sealing coupling, male thread. | |
| Gas return connector | 1/2 in. Aeroquip self-sealing coupling, female thread. | |
| Remote control receptacle | 24VAC, 2.7A inductive mates with P5 connector Type MS3106A | |
| Adsorber service schedule | 3 Years | |
| Weight | 250 lbs / 114 kg | 267 lbs / 121 kg |
